Some further efforts with JavaScript, exploring function construction classes and objects, courtesy of the Codecademy Find My Hat Project.

The initial goal was to code a basic “maze” game to perform the following:

  • Generate a grid maze, containing a start point (X), hat (^), holes (O) and solid ground (#) taking user input for size and difficulty
  • Display the current grid to the user
  • Take in user moves, recording their path (*) through the maze
  • Terminate the game as a loss if the user moves into a hole (O) or off the grid
  • Terminate the game as a win if the user moves into the hat (^)

Additional challenges included the following:

  • Start in a random location
  • Include a “hard mode” where new holes are generated randomly after a certain number of turns
  • Create a “maze solver” to check if the existing grid can be solved

Here’s some actual gameplay footage, from the full program!

The maze solver challenge proved to be pretty tricky, and I sank a lot of time into getting it working. I opted to code an A Star Search Algorithm with Manhattan Heuristic to check the grid before the game starts (resetting the grid if it was unsolvable) and in hard mode every time a new hole is added. My solution included creating a graph of every possible move from any available position on the grid, then performing a depth first search governed by the heuristic (a sum of the absolute differences in x and y position), so I guess it exhibits a very simplified form of Artificial Intelligence! As can be seen in the rather grandly named “gameplay footage” above, the game terminates in hard mode once an unwinnable grid is detected.

The source code I produced to run the game is below. I’m pretty pleased with how the maze solver ended up; the rest of the code would almost certainly benefit from some refactoring and input sanitisation when I have time.

'use strict';
const prompt = require('prompt-sync')({ sigint: true });
const Heap = require('collections/heap');

class Field {
    constructor(height, width, percentHoles, hard = false) {
        //set hard limit of 20 row by 50 column grid
        this._height = height % 21;
        this._width = width % 51;
        this._percentHoles = percentHoles;
        //create placeholder for goal grid reference
        this._goal = [];
        //create placeholder for graph indices
        this._graph = [];
        //set initial state of grid as unsolvable
        this._solvable = false;
        //construct a random grid based on construct parameters
        this._field = this.generateField();
        //set random start location
        this._location = this.randomStart();
        //placeholder graph of available moves for each coordinate for solver
        this._availableMoves = {};
        this._gameOver = false;
        this._hardMode = hard;
    }
    //implement getters
    get field() {
        return this._field;
    }
    get location() {
        return this._location;
    }
    get gameOver() {
        return this._gameOver;
    }
    get height() {
        return this._height;
    }
    get width() {
        return this._width;
    }
    get percentHoles() {
        return this._percentHoles;
    }
    get hardMode() {
        return this._hardMode;
    }
    get goal() {
        return this._goal;
    }
    get graph() {
        return this._graph;
    }
    get availableMoves() {
        return this._availableMoves;
    }
    get solvable() {
        return this._solvable;
    }
    //display the current grid
    print() {
        this._field.forEach(element => console.log(element.join('')));
    }
    //set the game condition to terminate
    endGame() {
        this._gameOver = true;
    }
    //mark each spot visited to create a path
    makeVisited() {
        this._field[this._location[0]][this._location[1]] = '*';
    }
    //return the content at existing location; if outside bounds of grid returns undefined.
    posStatus() {
        if (this.location[0] < 0 || this.location[1] < 0) {
            return undefined;
        } else if (this.location[0] >= this._field.length) {
            return undefined;
        } else if (this.location[1] >= this._field[this.location[0]].length) {
            return undefined;
        } else {
            return this._field[this.location[0]][this.location[1]];
        }
    }
    //prompt the user for a move
    getMove() {
        console.log('You are currently at X');
        console.log('Which way? W = UP, S = DOWN, A = LEFT, D = RIGHT');
        const choice = prompt();
        return choice;
    }
    //mark the current location as visited, then update current location according to user input
    move() {
        switch (this.getMove()) {
            case 'W':
                this.makeVisited();
                this._location[0] -= 1;
                break;
            case 'S':
                this.makeVisited();
                this._location[0] += 1;
                break;
            case 'A':
                this.makeVisited();
                this._location[1] -= 1;
                break;
            case 'D':
                this.makeVisited();
                this._location[1] += 1;
                break;
            default:
                console.log('Invalid choice, valid options are W,A,S,D.')
        }
    }
    //determine the consequences of a move; if valid and not a WIN mark current grid location with X
    moveOutcome() {
        if (this.posStatus() === undefined) {
            console.log('You stepped out of the field! GAME OVER');
            this.endGame();
        } else if (this.posStatus() === '*' || this.posStatus() === '#') {
            this._field[this._location[0]][this._location[1]] = 'X';
        } else if (this.posStatus() === '^') {
            console.log('You found your hat! You win! GAME OVER');
            this.endGame();
        } else if (this.posStatus() === 'O') {
            console.log('You fell down a hole! GAME OVER');
            this.endGame();
        } else if (this.posStatus() === 'X') {
            return;
        } else {
            console.log('Internal Error. Move not recognised.')
        }
    }
    //call relevant game methods in correct order to play the game
    playGame() {
        let turnCount = 0;
        //check if starting grid is solvable; if not, reset
        this.astarSolver();
        while (!this.solvable) {
            this._field = this.generateField();
            this._location = this.randomStart();
            this.astarSolver();
        }
        while (!this.gameOver) {
            this.print();
            if (!this.solvable) {
                console.log('The grid can no longer be solved! GAME OVER');
                this.endGame();
                continue;
            }
            this.move();
            this.moveOutcome();
            turnCount++;
            if (this.hardMode && turnCount % 3 === 0) {
                this.digHole();
                this.astarSolver();
            }
        }
    }
    //sanitise input and generate a random grid or default grid of 10 by 10 if bad input detected
    generateField() {
        if (this.height <= 0) {
            this._height = 10;
            console.log('Invalid height detected, using default 10 rows');
        };
        if (this.width <= 0) {
            this._width = 10;
            console.log('Invalid width detected, using default 10 rows');
        };
        const desiredTotal = this.height * this.width;
        const holeNumber = Math.floor(this.percentHoles * desiredTotal / 100);
        const fieldComponents = ['^'];
        let randomField = [];
        for (let j = 0; j < this.height; j++) {
            randomField.push([]);
        };
        for (let i = 0; i < holeNumber; i++) {
            fieldComponents.push('O');
        };
        while (fieldComponents.length < desiredTotal) {
            fieldComponents.push('#');
        };
        for (let k = 0; k < this.height; k++) {
            for (let m = 0; m < this.width; m++) {
                randomField[k][m] = fieldComponents.splice(Math.floor(Math.random() * fieldComponents.length), 1)[0];
                //update this._goal with the instance grid ref of target ^ hat for solver
                if (randomField[k][m] === '^') {
                    this._goal = [k, m];
                }
                //create graph of locations for solver
                this._graph.push([k, m]);
            }
        }
        return randomField;
    }
    //set up a random start location and mark with X
    randomStart() {
        let startLocation = this.randomLocation();
        //check to ensure start point is not the goal
        while (this._field[startLocation[0]][startLocation[1]] === '^') {
            startLocation = this.randomLocation();
        }
        this._field[startLocation[0]][startLocation[1]] = 'X';
        return startLocation;
    }
    //generate a random hole for hard mode in locations that are not occupied, the ^ or already a hole.
    digHole() {
        let newHoleLoc = this.randomLocation();
        while (this.field[newHoleLoc[0]][newHoleLoc[1]] === '^' || this.field[newHoleLoc[0]][newHoleLoc[1]] === 'O' || this.field[newHoleLoc[0]][newHoleLoc[1]] === 'X') {
            newHoleLoc = this.randomLocation();
        }
        //printed a grid reference to more easily check digHole was working on a big grid while debugging!
        console.log(`A new hole appears at ${newHoleLoc}!`);
        this._field[newHoleLoc[0]][newHoleLoc[1]] = 'O';
    }
    //helper method to generate random location on the grid
    randomLocation() {
        const x = Math.floor(Math.random() * this.height);
        const y = Math.floor(Math.random() * this.width);
        const randLocation = [x, y];
        return randLocation;
    }
    //helper method to provide a Manhattan graph heuristic value for solver method
    manhattanHeuristic(location) {
        const y_distance = Math.abs(location[0] - this.goal[0]);
        const x_distance = Math.abs(location[1] - this.goal[1]);
        return x_distance + y_distance;
    }
    //helper method to check if cell exists in graph for calculating available moves
    checkCell(cell) {
        for (let i = 0; i < this.graph.length; i++) {
            if (this.graph[i][0] === cell[0] && this.graph[i][1] === cell[1]) {
                return true;
            }
        }
        return false;
    }
    //helper method to provide Manhattan graph of available moves for any given location
    notHole() {
        let possibleMoves = {};
        for (const coordinate in this.graph) {
            const thisRow = this.graph[coordinate][0];
            const thisColumn = this.graph[coordinate][1];
            if (this.field[thisRow][thisColumn] === 'O') {
                continue;
            } else {
                possibleMoves[coordinate] = [];
                const upCell = [thisRow - 1, thisColumn];
                const downCell = [thisRow + 1, thisColumn];
                const leftCell = [thisRow, thisColumn - 1];
                const rightCell = [thisRow, thisColumn + 1];
                if (this.checkCell(upCell)) {
                    const upCellContent = this.field[upCell[0]][upCell[1]];
                    if (upCellContent != 'O') {
                        possibleMoves[coordinate].push([upCell, 1]);
                    }
                }
                if (this.checkCell(downCell)) {
                    const downCellContent = this.field[downCell[0]][downCell[1]];
                    if (downCellContent != 'O') {
                        possibleMoves[coordinate].push([downCell, 1]);
                    }
                }
                if (this.checkCell(leftCell)) {
                    const leftCellContent = this.field[leftCell[0]][leftCell[1]];
                    if (leftCellContent != 'O') {
                        possibleMoves[coordinate].push([leftCell, 1]);
                    }
                }
                if (this.checkCell(rightCell)) {
                    const rightCellContent = this.field[rightCell[0]][rightCell[1]];
                    if (rightCellContent != 'O') {
                        possibleMoves[coordinate].push([rightCell, 1]);
                    }
                }
            }
        }
        return possibleMoves;
    }
    //helper method to calculate a vertex ID from a given location
    vertexId(location) {
        return (location[0] * this.width) + (location[1])
    }
    astarSolver() {
        //let count = 0;
        //refresh available moves from current location every time astar solver is called
        this._availableMoves = this.notHole();
        let pathsAndDistances = {};
        const startId = this.vertexId(this.location);
        const targetId = this.vertexId(this.goal);
        for (const vertex in this.availableMoves) {
            pathsAndDistances[vertex] = [Infinity, [startId]];
        }
        pathsAndDistances[startId][0] = 0;
        let verticesToExplore = new Heap([[0, startId]]);
        while (verticesToExplore.length > 0 && pathsAndDistances[targetId][0] === Infinity) {
            const currentValues = verticesToExplore.pop();
            const currentDistance = currentValues[0];
            const currentVertex = currentValues[1];
            for (let i = 0; i < this.availableMoves[currentVertex].length; i++) {
                const neighbour = this.availableMoves[currentVertex][i][0];
                const neighbourId = this.vertexId(neighbour);
                const edgeWeight = this.availableMoves[currentVertex][i][1];
                const newDistance = currentDistance + edgeWeight + this.manhattanHeuristic(neighbour);
                const newPath = pathsAndDistances[currentVertex][1];
                //pathsAndDistances[currentVertex][1].push(this.vertexId(neighbour));
                newPath.push(this.vertexId(neighbour));
                if (newDistance < pathsAndDistances[neighbourId][0]) {
                    pathsAndDistances[neighbourId][0] = newDistance;
                    pathsAndDistances[neighbourId][1] = newPath;
                    verticesToExplore.push([newDistance, neighbourId]);
                    //count++;
                }
            }
        }
        if (pathsAndDistances[targetId][0] === Infinity) {
            this._solvable = false;
        } else {
            this._solvable = true;
        }
    }
}

//factory function to create a new instance of the game according to user preferences and start play
const findMyHat = () => {
    console.log('Enter desired grid height (max 20):');
    const rows = prompt();
    console.log('Enter desired grid width (max 50):');
    const columns = prompt();
    console.log('Enter percentage of starting holes (0-75):');
    const percent = prompt();
    console.log('Activate hard mode Y/N');
    const mode = prompt();
    let modeActive;
    if (mode === 'Y') {
        modeActive = true;
    } else {
        modeActive = false;
    }
    if (percent < 0) {
        percent = 0;
    } else if (percent > 75) {
        percent = 75;
    }
    const myField = new Field(rows, columns, percent, modeActive);
    myField.playGame();
}

//call the game function!
findMyHat();
